PACKAGED UNIT
DP-CF36UUMR2
DEPLUS PACKAGED UNIT 3 TON UP TO 13.4 SEER2 R32
- Energy-efficient compressor
- Refrigeration-grade premium 7mm copper tubing and aluminum fin condenser coil
- Specialized time-delay defrost technology
- Acoustically engineered sound control blanket for quiet operation
- Baked enamel finish protects the system from the elements
- Cooling range from 54~126°F
- Heating range from 14~90°F
Technical Specs
For detailed technical information, please refer to the listed specifications. You will find comprehensive data on cooling capacity, power requirements, dimensions, and other essential performance details to help you make an informed decision.
Want to compare models?
In our product brochure you will find the specifications for all our models
| Feature | . | . | 3 TON MODEL |
|---|---|---|---|
| Model | ART-CF36USMR3-D01/SE134 | ||
| DEPLUS Model | DP-CF36UUMR2 | ||
| Power Supply | 208-230V/1N/60Hz | ||
| Cooling Performance | Cooling Capacity | Btu/h | 32600 |
| EER2 | Btu/h.W | 11.8 | |
| SEER2 | Btu/h.W | 13.4 | |
| Rated CFM | 1330 | ||
| System Power | KW | 2.75 | |
| Heating Performance | Heating Capacity | Btu/h | / |
| HSPF2 | Btu/h.W | / | |
| Rated CFM | / | ||
| System Power | KW | / | |
| Compressor | Number / Type | 1 / Scroll | |
| Outdoor Fan | Fan Type | Propeller | |
| Number Used | 1 | ||
| Diameter | inch | 22 | |
| Motor Type | PSC | ||
| Moyor Capacitor | μF | 6 | |
| Motor Horse Power | HP | 1/7 | |
| Indoor Fan | Fan Type | Centrifugal | |
| Number Used | 1 | ||
| Diameter | inch | 10x10 | |
| Motor Type | ECM | ||
| Moyor Capacitor | μF | / | |
| Motor Horse Power | HP | 1/2 | |
| Size | Packing(DxWxH) | inch | 52-3/8 × 38 × 25-4/5 |
| Shipping per SDT40HQ | 80 | ||
